FO1D(FV1D)
Single seal,Unbalanced,Independent of direction of rotation -
169
Single seal,Unbalanced,Independent of direction of rotation -
113
Single seal,Unbalanced,Independent of direction of rotation -
112
Single seal,Unbalanced,Independent of direction of rotation -
120
Single seal,Unbalanced,Dependent on direction of rotation -
110
Single seal,Balanced,Independent of direction of rotation -
104
Single seal,Unbalanced,Independent of direction of rotation -
T155
Single seal,Unbalanced,Dependent on direction of rotation
FO1D(FV1D)
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber:≤0.8MPa
Temperature in the sealed chamber：-20℃~180℃
Linear velocity：≤10m/Sec
Shaft:25-100
169
model：
Technical parameters：
Mediums to be sealed:Crystallization chemical medium,such as alkali salt solution,etc.
Pressure in the sealed chamber:≤0.5MPa
Temperature in the sealed chamber：-20℃~120℃
Linear velocity:≤15m/Sec
Shaft：30-60mm
113
model：
Technical parameters：
Mediums to be sealed:Water,oil,etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber:-20℃~150℃
Linear velocity：15m/Sec
Shaft:18-65
112
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：-20℃~180℃
Linear velocity：≤15m/Sec
Shaft:20-130
120
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber:-20℃~150℃
Linear velocity:≤15m/Sec
Shaft:14-80mm
110
model：
Technical parameters：
Mediums to be sealed:Water,oil,etc.moderate corrosive and below medium
Pressure in the sealed chamber：≤3MPa
Temperature in the sealed chamber：-50℃~180℃
Linear velocity：≤15m/Sec
Shaft：20-120mm
104
model：
Technical parameters：
Mediums to be sealed:Water,oil,ect. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealede chamber:-50℃-180℃
Linear velocity:≤15m/Sec
Shaft:18-120mm
T155
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber：≤0.7MPa
Temperature in the sealed chamber：-20℃~120℃
Linear velocity：≤13m/Sec
Shaft：10-40
