700
Single seal,Unbalanced,Independent of direction of rotation -
800
Single seal,Unbalanced,Independent of direction of rotation -
208
Double seal,Unbalanced,Independent of direction of rotation -
108u
Single seal,Unbanlanced,Dependent on direction of rotation -
GY
Single seal,Balanced,Independent of direction of rotation -
GX
Single seal,Unbalanced,Independent of direction of rotation -
5EX
Single seal,Unbalanced,Dependent on direction of rotation -
FO2D(FV2D)
Single seal,Unbalanced,Independent of direction of rotation
700
model：
Technical parameters：
Mediums to be sealed:Water,oil,etc. weak corrosive medium
Pressure in the sealed chamber：≤0.3MPa
Temperature in the sealed chamber：-20℃~120℃
Linear velocity：≤10m/Sec
Shaft：14-30mm
800
model：
Technical parameters：
Mediums to be sealed:Water,oil,etc.weak corrosive medium
Pressure in the saled chamber:≤0.3MPa
Temperature in the sealed chamber:-20℃~120℃
Linear velocity：≤10m/Sec
Shaft：10-16mm
208
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber:≤0.8MPa
Temperature in the sealed chamber：-20℃~100℃
Linear velocity：≤5m/Sec
Shaft：10-40mm
108u
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate corrosive and below medium
Pressure in the sealed chamber:：≤1MPa
Temperature in the sealed chamber：-10℃~150℃
Linear velocity：≤15m/Sec
Shaft：35-70mm
GY
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber:≤4MPa
Temperature in the sealed chamber：-20℃~150℃
Linear velocity：≤10m/Sec
Shaft：30-100mm
GX
model：
Technical parameters：
e sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber:≤0.8MPa
Temperature in the sealed chamber:-20℃~120℃
Linear velocity:≤3m/Sec
Shaft:30-90
5EX
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：0℃~120℃
Linear velocity：≤10m/Sec
Shaft:20-70mm
FO2D(FV2D)
model：
Technical parameters：
Mediums to be sealed:Water,oil,acid,alkali,etc. moderate and below corrosive chemical medium
Pressure in the sealed chamber：≤0.8MPa
Temperature in the chamber：-20℃~180℃
Linear velocity：≤10m/Sec
Shaft：25-100
